Custom AV Amplifier Enclosure定制 AV 功放钣金外壳
Steel housings for home theatre receivers, multi-channel power amplifiers and commercial sound systems — top louvres and side perforations laid out around the real convection path, front panel cut and silkscreened for optical, coaxial, AUX and Bluetooth inputs plus subwoofer and surround outputs, with a matte powder-coated finish. Folded returns and stiffening ribs keep the case from ringing, and grounding tabs keep it from humming. CNC bending at ±0.1 mm, free CAD design, MOQ 1 piece.
面向家庭影院接收机、多声道功率放大器与商用音响系统的钢制外壳——顶部百叶与侧面冲孔按真实对流路径布置，前面板按光纤、同轴、AUX 与蓝牙输入以及低音炮、环绕输出接口开孔并丝印标识，表面为哑光粉末喷涂。折边与加强筋抑制箱体共振，接地片消除交流哼声。数控折弯精度 ±0.1 mm，免费 CAD 设计，1 件起订。
Product Overview
产品概述
An amplifier housing gets blamed for three faults it did not cause, and each one has a different cure. Mechanical hum is a stiffness problem, not an electrical one. Overheating is an airflow path problem, not a hole-count problem. And a front panel that looks right in the render but sits 1 mm off the connector bezel is a drawing problem that only shows up on the assembly line.
功放外壳常被指责三种其实并非它造成的毛病，而三者的解法各不相同：机械嗡声是刚度问题，不是电气问题；过热是气流路径问题，不是开孔数量问题；而面板在渲染图里看着正好、装到连接器面板上却差 1 mm，是图纸问题——它只在产线上才暴露。
We build these in steel rather than aluminium for a reason that has nothing to do with looks. A mains transformer sitting two centimetres from a flat panel will find that panel and drive it, and steel is both the stiffer material per unit of cost and the better magnetic shield around the transformer itself. Where the shell is expected to carry heat away as well, or where the unit is carried to gigs every week, we quote aluminium instead and say why.
我们选用钢材而非铝材，原因与外观无关：距离平板两厘米的电源变压器，终会找到那块平板并把它驱动起来；而钢既在单位成本下刚度更高，也是变压器周围更好的磁屏蔽材料。只有当壳体本身还要承担散热，或设备需要每周搬运时，我们才会改报铝材并说明理由。
The vent layout is decided from your dissipation, not copied from a previous model. Cool air enters low at the sides, picks up heat across the output stages and leaves through the top, so convection and the vents push the same way. Top louvres are formed with a downward-facing lip, which sheds dust falling from above instead of collecting it, and their open area is sized against the heat figure you give us rather than filled in until it looks generous.
散热孔布局由您的耗散热量决定，而非套用前一款机型。冷空气从侧面低位进入，流经功率输出级带走热量，再从顶部排出——如此，自然对流与开孔方向一致。顶部百叶成型时带朝下的唇边，能抖落上方落下的灰尘而非积存；开孔率按您给出的热耗数据确定，而不是凭观感开到「看起来够大」。
Nothing here is stock. Every enclosure we ship began as your connector list, your transformer footprint and your dissipation figure, and the drawings behind it are drawn and revised free of charge until you sign them off.
这里没有现货件。我们交付的每一台功放外壳，都起自您的接口清单、变压器占位与热耗数据；其图纸由我们免费绘制并修改，直至您签核为止。
Specifications & Capability Range
规格与能力范围
| Material | 材料 | SPCC cold-rolled steel primary; SUS304 or aluminium 5052 quoted for premium or weight-driven builds | 主选 SPCC 冷轧钢；高端或减重机型可报 SUS304 或 5052 铝板 |
|---|---|---|---|
| Thickness | 板厚 | 1.0 - 1.5 mm, selected against transformer mass, panel stiffness and rack or shelf duty | 1.0 - 1.5 mm，按变压器重量、面板刚度与上架或置架用途选定 |
| Structure | 结构 | Folded cover and base with folded returns; removable rear panel for connector access | 折弯成型的盖体与底座，带内折边；后板可拆以便接线 |
| Cutting | 切割 | Fiber laser cutting, ±0.05 mm on contour, burr-controlled and fully deburred | 光纤激光切割，轮廓精度 ±0.05 mm，毛刺受控并全数倒角去毛刺 |
| Bending | 折弯 | CNC press brake, ±0.1 mm, bend angle up to 160° | 数控折弯，精度 ±0.1 mm，折弯角度最大 160° |
| Ventilation | 散热开孔 | Top louvre arrays with downward lip; side perforation bands; open area sized to your dissipation | 带朝下唇边的顶部百叶阵列；侧面冲孔带；开孔率按您的热耗数据确定 |
| Front Panel | 前面板 | Input and output apertures cut to your connector part numbers, matched to the bezel you ship | 输入输出开孔按您的连接器型号制作，与实际出货的面框匹配 |
| Noise Control | 噪声控制 | Stiffening ribs and folded returns; stiffened transformer mounting area; rubber feet | 加强筋与内折边；变压器安装区加强；配橡胶脚垫 |
| Grounding | 接地 | Dedicated grounding tabs and masked contact pads kept conductive through finishing | 专用接地片与遮蔽触点，在表面处理后仍保持导电 |
| Marking | 标识 | Silkscreen legends for ports and ratings, applied after finishing; laser marking where solvents are used | 端口与额定值标识于表面处理之后丝印；接触溶剂处改用激光打标 |
| Surface Finish | 表面处理 | Matte powder coating, black or custom RAL; brushing or anodizing on aluminium builds | 哑光粉末喷涂，黑色或定制 RAL 色；铝制件可选拉丝或阳极氧化 |
| Welding | 焊接 | Spot welding / argon-arc / full-seam laser welding per joint requirement | 按接头要求采用点焊、氩弧焊或满缝激光焊 |
| MOQ | 起订量 | 1 piece — prototype and pilot batch friendly | 1 件起，支持打样与小批量试产 |
| Lead Time | 交期 | Standard builds 7 - 15 working days, custom builds 20 - 30 days; prototype schedule quoted by complexity tier | 标准件 7 - 15 个工作日，定制件 20 - 30 天；打样周期按复杂度分档报价 |
All parameters are adjustable to your project. Contact us for a tailored engineering proposal.
以上参数均可按项目调整，欢迎联系我们获取定制工程方案。
Engineering Highlights
工艺要点
Vents Placed for Convection, Not Symmetry
开孔顺对流，而非求对称
Cool air enters low, warms across the output stages and leaves through the top, so we put the intake band near the base and the exhaust louvres across the lid. A pattern that looks balanced but puts both at the same height short-circuits the flow and leaves a hot pocket under the lid.
冷空气低位进入，流经功率输出级升温后从顶部离开——因此我们让进风冲孔带靠近底部，出风百叶横跨顶盖。看着均衡但两者等高的孔型会形成气流短路，在顶盖下方留下热区。
A Case That Does Not Ring
不共振的箱体
Large flat panels over a mains transformer hum. We shorten every span with folded returns and stiffening ribs so the natural frequency of the panel sits above what the transformer can excite, and isolate the transformer on a reinforced mounting area instead of the open lid.
变压器上方的大平面会嗡嗡作响。我们用内折边与加强筋缩短每一段跨度，使面板固有频率高于变压器所能激励的范围；并把变压器固定在加强过的安装区，而不是悬空的顶盖上。
Grounding That Survives Finishing
处理后依然导通的接地
Powder coat is an insulator, which is what you want everywhere except at a bonding point. We define those points at drawing stage and keep them masked or machined, so a star ground stays continuous to the chassis after the part comes off the line.
粉末涂层是绝缘的——除了搭接点，这正是我们想要的。但我们在图纸阶段就明确这些接点并做遮蔽或后加工，使星形接地在零件下产线后仍与壳体保持连续。
Apertures Cut to Real Connectors
按真实连接器开孔
Input and output holes follow your connector part numbers, not a template, and they are checked on the first article with those connectors actually fitted. A 0.5 mm mismatch shows up as a panel that will not sit flat, and it is far cheaper to find on our bench than on yours.
输入输出孔按您的连接器型号而非模板开孔，并在首件上用真实连接器实装校核。0.5 mm 的偏差会表现为面板装不平；这个问题在我们的工作台上发现，远比在您的产线上发现便宜。
Applications
应用场景
Home Theatre Receivers
家庭影院接收机
Multi-channel housings with the input and speaker layout, vent area and finish chosen for a living room rather than a rack room.
多声道功放外壳，输入输出布局、散热面积与表面处理按客厅环境而非机房环境确定。
Power Amplifiers
功率放大器
Two-channel and multi-channel builds with a stiffened transformer area and a convection path sized to continuous output.
两声道与多声道机型，变压器区加强，对流通道按连续输出功率确定。
Commercial Sound Systems
商用音响系统
Enclosures for installed audio in retail, hospitality and education, with tamper-resistant covers and labelled rear panels.
用于零售、酒店与教育等场所的固定安装音响，配防拆盖板与标识清晰的后板。
Preamplifiers & DAC Housings
前级与解码器外壳
Small-signal units where the shielding and the grounding layout matter more than the vent area.
小信号设备，屏蔽与接地布局的重要性高于散热开孔面积。
From RFQ to Delivery
从询价到交付
1 · Send Requirements
1 · 提交需求
Connector list, transformer footprint, panel layout, size limits, dissipation and finish — a sketch with key dimensions is enough. Quote within 24 hours.
连接器清单、变压器占位、面板布局、尺寸限制、热耗与表面处理，带关键尺寸的草图即可。24 小时内报价。
2 · Free DFM & CAD
2 · 免费 DFM 与图纸
Vent path, stiffening layout, grounding points, bend sequence and seam gasketing reviewed, with production-ready drawings revised until you approve.
评审风道走向、加强布局、接地点、折弯顺序与接缝密封，配量产图纸，修改至您确认为止。
3 · Prototype & QC
3 · 打样与检验
First article with dimensional report and photos; real connectors, bezels and board fit inspected before batch release.
首件附尺寸报告与照片；量产前检查真实连接器、面框与板卡的装配贴合。
4 · Batch & Ship
4 · 量产与发运
Production with in-process inspection at every critical step, export plywood packing, FOB / CIF / DDP.
量产并对每个关键工序执行过程检验，出口胶合板包装，支持 FOB / CIF / DDP。
Frequently Asked Questions
常见问题
What is the minimum order quantity?起订量是多少？
MOQ is 1 piece. An amplifier enclosure is usually signed off by ear as much as by drawing, so we build a prototype you can listen to before quoting the batch from the validated design.1 件起订。功放外壳的签核往往既靠图纸也靠耳朵——所以我们先做一台您可以试听的样机，再以验证后的设计报量产价。
Can you cut the front panel to our input and speaker layout?能按我们的输入与音箱接口布局开前面板吗？
Yes. Optical, coaxial, AUX and Bluetooth input positions plus subwoofer and surround output apertures are laser cut to your connector part numbers, not to a generic template. We verify each hole on the first article with your real connectors fitted.可以。光纤、同轴、AUX 与蓝牙输入位，以及低音炮、环绕输出开孔，均按您的连接器型号激光开孔，而非套用通用模板。首件上我们用您的真实连接器实装逐孔校核。
How do you stop the enclosure from buzzing?如何避免箱体嗡嗡响？
A flat panel over a mains transformer is a sounding board. We break the panel into shorter spans with folded returns and stiffening ribs, isolate the transformer on a stiffened mounting area, and fit rubber feet so the case is not coupled into the shelf.变压器上方的平板就是一块共鸣板。我们用内折边与加强筋把面板切分成更短的跨度，把变压器固定在加强过的安装区，并配橡胶脚垫使箱体不与置架形成耦合。
Where should the vents go on an amplifier enclosure?功放外壳的散热孔应该开在哪里？
Low at the sides for intake and high across the top for exhaust, so convection works with the air instead of against it. Top louvres are angled so they shed dust falling from above, and the open area is sized to your dissipation rather than copied from another model.侧面低位进风、顶部横跨出风，使自然对流与气流同向而非相抵。顶部百叶带倾角以抖落上方落灰；开孔率按您的热耗数据确定，而非照搬其他机型。
Steel or aluminium for an amplifier enclosure?功放外壳用钢还是铝？
Steel for most builds, because it is stiff per unit cost, it is the better magnetic shield around a mains transformer and it takes a powder coat well. Aluminium is the call where the shell itself has to act as a heat spreader or where the unit is carried often.多数机型用钢：单位成本下刚度更高、对电源变压器的磁屏蔽更好，也更适合粉末喷涂。只有当壳体本身要承担散热，或设备需要经常搬运时，才选铝材。
What do you need to quote?报价需要哪些资料？
A panel drawing with connector positions is ideal, but a marked-up photo, a hand sketch with key dimensions or a sample unit is enough to start. We reply with a DFM review, drawings and a factory-direct quote within 24 hours.带接口位置的面板图纸最好，但标注过的照片、带关键尺寸的手绘草图或一台样机也足够起步。我们 24 小时内回复 DFM 评审、图纸与工厂直供报价。
Need a quote for a custom AV amplifier enclosure?
需要定制 AV 功放外壳报价？
Send a connector list, a panel layout, a transformer footprint or a sample unit — we reply with a DFM review, drawings and quote within 24 hours.
发送接口清单、面板布局、变压器占位或一台样机，我们 24 小时内回复 DFM 评审、图纸与报价。
